PE-RT HIGH TEMPERATURE HDPE
It significantly expands the operation window for polyethylene pipes with pressure ratings up to 180°F. We provide a full range of pipe sizes, pressure capabilities, molded and fabricated fittings to customize a solution for your project. PE-RT pipe systems follow the same fusion parameters as standard PE4710 and native backfill material from a trench (sandless installation) can be used for shallow, non-traffic applications. This product can be used for high-temperature industrial, mining, oil and gas gathering applications.
- ASTM D3350 Cell Class PE445574C
- ASTM D2837 HDB = 800 psi at 180°F
- ASTM F2619 HDPE Line Pipe
- API 15 LE Polyethylene Line Pipe
- ASTM F714 Polyethylene Pipe
- ASTM D3261 and D2513 (Molded Fittings)
- ASTM F2206 (Fabricated Fittings)
- Higher permissible operating temperatures compared to standard PE4710 products
- Allows continuous operation at temperatures from -49°F (-45°C) to 180°F (82°C)
- Intermittent operating temperatures up to 203°F (95°C) are possible for some applications
- 20 times PE4710 requirements for stress crack resistance
- Allows use of native backfill material from trench (sandless installation) for shallow, non-traffic applications
- Follows same fusion parameters as standard PE4710 pipes
- Patented stabilizer system for high temperature oxidative environments with ASTM D3350 CC3 rating
- Full range of pipe sizes, pressure capabilities, molded and fabricated fittings
PlatinumStripe® 1800 PE-RT significantly expands the operation window for polyethylene (PE) pipes with pressure ratings up to 180°F. PlatinumStripe® 1800 PE-RT is intended for high-temperature industrial, mining, oil and gas gathering applications.
